MASTER LEDspot LV - The ideal solution for spot lighting



MAS LEDspotLV 3.5-20W 827 MR11 24D


Specifications

General Information
Cap-Base
GU4
Bulb Shape
MR11  [ 1.375inch/35mm]

Nominal Lifetime (Nom)
40000 h
Switching Cycle
50000X
Technical Type
3.5-20W




Light Technical
Color Code
827  [ CCT of 2700K]
Beam Angle (Nom)
24 °
Light Distribution
-
Luminous Flux (Nom)
210 lm
Luminous Flux (Rated) (Nom)
210 lm
Luminous Intensity (Nom)
1000 cd
Color Designation
Warm White (WW)
Rated Beam Angle
24 °
Correlated Color Temperature (Nom)
2700 K
Luminous Efficacy (rated) (Nom)
60.00 lm/W
Color Consistency
<6
Color Rendering Index (Nom)
80
LLMF At End Of Nominal Lifetime (Nom)
70 %
Luminous Flux In 90° Cone (Rated)
200 lm







Operating and Electrical
Input Frequency
50 to 60 Hz
Power (Rated) (Nom)
3.5 W
Lamp Current (Nom)
640 mA
Wattage Equivalent
20 W
Starting Time (Max)
0.5 s
Warm Up Time To 60% Light (Nom)
instant full light
Power Factor (Nom)
0.5
Voltage (Nom)
12 V




Temperature
T-Case Maximum (Nom)
94 °C

Controls and Dimming
Dimmable
No

Approval and Application
Suitable For Accent Lighting
Yes
Energy Efficiency Label (EEL)
A+
Energy Consumption kWh/1000 h
4 kWh


Product Data
Full product code
871869641019600
Order product name
MAS LEDspotLV 3.5-20W 827 MR11 24D
EAN/UPC - Product
8718696410196
Order code
929001123802
Numerator - Quantity Per Pack
1
Numerator - Packs per outer box
12
Material Nr. (12NC)
929001123802
Net Weight (Piece)
0.024 kg
























Installation Diagrams
3.5-20 W, 4-20W GU4 MR11
3.5-20 W, 4-20W GU4 MR11





Photometrics
